VLX 100 Pivot Door

VLX 100 Pivot Door in Fort Lauderdale, FL | Westlight Windows Fort Lauderdale

The VLX 100 Pivot Door is a heavy-duty aluminum entry door that rotates on a vertical center axis instead of swinging on side hinges. That single design change transforms a doorway into a sculptural focal point, letting you run glass panels up to 60 inches wide and 10 feet tall. Westlight Windows Fort Lauderdale is an authorized ViewLux installation partner, which means we order, deliver, and install this door to the manufacturer’s exacting standards. If you’re planning a modern home, a waterfront renovation, or a luxury condo upgrade anywhere from Victoria Park to Rio Vista, call us at (754) 354-5397 to start with a free measurement.

Call (754) 354-5397

Product Overview – VLX 100 Pivot Door

The VLX 100 is what architects reach for when a standard swing door feels too ordinary. The pivot system places the rotation point off to one side, so the door moves on a completely different arc than anything your guests have walked through before. The result is less mechanical noise, a smoother throw, and a visual weight that says the house was designed, not just assembled.

What separates this from a typical aluminum door is the engineering underneath. The profile stretches 2.56 inches wide, giving the frame real structural presence. Wall thickness runs 0.098 inches, which means the extrusion resists flexing even when you’re working with a 60-by-120-inch slab of glass. That’s not a door you nudge open with your hip. It’s a piece of architecture you lean into.

In Fort Lauderdale, where indoor-outdoor living runs nine months of the year, this door makes a specific kind of sense. It frames whatever is on the other side, a pool deck in Las Olas Isles, a courtyard in Sailboat Bend, a private garden in Coral Ridge, without the visual clutter of conventional hinges and frames. Westlight Windows Fort Lauderdale handles the complete order through installation, so the door arrives as a coordinated system rather than a pile of parts. Call (754) 354-5397 to talk through what a VLX 100 would look like on your entry.

Technical Specifications

• Profile width: 2.56 inches of extruded aluminum per frame member
• Wall thickness: 0.098 inches, engineered for stiffness on oversized panels
• Maximum span: up to 60 inches wide × 120 inches tall
• Glass options: Clear, Frosted, Obscure, Low-E, Tempered, Laminated
• Finish options: Premium Black, Pure White, Anodized Silver, Bronze, Champagne, Teak Wood
• Rotation: vertical center-axis pivot hardware, floor- and header-mounted
• Compliance: installed to AAMA 2400/2410 standards, AAMA 812 perimeter sealant protocol
• Thermal package: thermal break technology, NFRC-rated energy performance
• Wind resistance: wind-load rated for South Florida climate requirements

Performance Features

Thermal Efficiency

The frame uses thermal break technology, which separates the interior and exterior aluminum faces to stop heat transfer through the metal. In Fort Lauderdale’s August humidity, that means your air-conditioned air stays inside and the afternoon sun stays out. Every VLX 100 installation is NFRC-rated for energy performance.

Acoustic Performance

Aluminum frames this substantial, combined with the right glass selection, meaningfully reduce outside noise. Customers on Federal Highway, Andrews Avenue, or near the Brightline corridor notice the difference immediately. Laminated glass adds another layer of sound damping if you want the quietest possible entry.

Airtightness & Weather Seal

We install every perimeter joint with AAMA 812 low-expansion foam sealant, then add compression weatherstripping at the operable panel. The result is an entry that doesn’t whistle during afternoon thunderstorms and doesn’t leak conditioned air when the HVAC is running hard.

Waterproofing

Fort Lauderdale gets roughly 60 inches of rain a year, much of it arriving sideways during summer squalls. The VLX 100’s drainage design, paired with our AAMA 2400/2410 installation method, channels water away from the threshold instead of letting it pool at the sill. We water-test every install before we call the job done.

Wind Resistance

South Florida building codes are written for hurricane-force wind events, and the VLX 100 is wind-load rated for those requirements. When paired with impact-resistant laminated glass, the door meets the same protective standards required of windows in high-velocity hurricane zones across Broward County.

Security & Hardware

The pivot mechanism distributes the door’s weight across a floor-mounted bearing and a header pin, which makes the panel significantly harder to force than a standard hinged door. Add a multi-point locking option and you have a front entry that looks like a gallery installation and locks like a vault.

Color & Glass Options

Six finishes change the personality of the VLX 100 before you even select glass. Premium Black and Pure White are the ones we order most in Fort Lauderdale’s newer modern builds, especially in Victoria Park and the condo corridors along the Intracoastal. Anodized Silver reads as clean and commercial, which suits loft-style interiors. Bronze and Champagne add warmth without going traditional, and Teak Wood lets an aluminum door pass as a rich timber statement while holding up to salt air and humidity.

Glass selection depends mostly on what faces the street. Clear glass maximizes the visual connection but offers little privacy. Frosted and Obscure glass keep sightlines blocked while still passing daylight, ideal for entries that face a sidewalk in Harbordale or Progresso Village. Low-E coatings cut solar gain, which matters when the western sun hits your entry at 5 p.m. Tempered glass is a safety default, and Laminated glass gives you the impact resistance and sound control we discussed above. Most Fort Lauderdale clients end up combining laminated with Low-E, and we’ll walk you through the tradeoffs during your estimate.

Installation by Westlight Windows Fort Lauderdale in Fort Lauderdale

A pivot door is not a forgiving install. The slab weighs hundreds of pounds, the pivot points must align to the millimeter, and every seal has to hold against South Florida’s rain, wind, and humidity. That’s why ViewLux authorizes select partners to install the VLX 100, and why Westlight Windows Fort Lauderdale follows a strict protocol on every job.

We start with a pre-install inspection of the rough opening, checking the subfloor for deflection and the header for square. Then we set the frame level, plumb, and square, shimming precisely so the pivot axis runs true. The door is hung, the sweep and weatherstripping are tuned, and all perimeter joints get AAMA 812 low-expansion foam sealant. We install to AAMA 2400/2410 standards, then run a final water test, inspect the operation, and clean the job site before we leave.

Here’s the part most homeowners don’t hear until something goes wrong: an improperly installed pivot door voids the manufacturer’s warranty. The glass fails, the frame twists, the seals tear, and you’re holding the bill. In Fort Lauderdale’s climate, shortcuts around waterproofing show up within a season or two. Our team installs these doors correctly the first time, so your warranty stays intact and your entry stays dry. We’ve handled projects in Rio Vista, Colee Hammock, Tarpon River, and across greater Fort Lauderdale, and we’d be glad to show you completed installations nearby.

Frequently Asked Questions – VLX 100 Pivot Door

Get a Quote – VLX 100 Pivot Door in Fort Lauderdale

The fastest way to price this door is to let us measure your opening and walk you through the glass, finish, and hardware choices in person. Westlight Windows Fort Lauderdale provides free on-site measurements and written quotes for every VLX 100 project. Call (754) 354-5397 to schedule yours, or stop by and talk through the options with our Fort Lauderdale team.

Written by the team at Westlight Windows Fort Lauderdale, serving Fort Lauderdale and surrounding Broward County since our founding. We install every VLX 100 Pivot Door as if it were going on our own front entry.
